Temperature And Level Controller With OLG
We are engaged in offering a comprehensive range of Temperature And Level Controller With OLG the clients. Our customers can avail these products in different specifications from us.
Product Description
Tank top mounting type Digital temperature and level indicator / controller with oil level gauge is used to indicated and control both temperature and level of hydraulic oils in machine tool industry.
Digital temperature and level indicator / controller with oil level gauge incorporates PTFE / PVDF insulated sense electrode, stainless steel gauge electrode, passivated MS mouting flange and ABC plastic enclosure with houses the electronics and 6 core cable for external electrical connections. Oil level gauge consists of polyurethane foam float, aluminium profile structure and clear acrylic tube.
Solid state temperature transducer is housed at bottom of sense electrode and its out put is proportional to the surrounding liquid temperature and the same is converted and indicated in °C. Capacitance variation between sense electrode and gaurd electrode which is proportional to the liquid level between the two electrodes is converted in to electrical signal using unique mixed signal technology and indicated in % between two marked locations. Two programmable set points are provided for temperature and level for external control. Indicator can be programmed to display either temperature / level alternatively or only temperature / level.
